Planet SGSW-24240R [38/328] User s manual of wgsw 24040 wgsw 24040r sgsw 24040 sgsw 24040r

User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

Figure 2-22 Pull out the SFP transceiver

Never pull out the module without pull the handle or the push bolts on the module. Direct pull

out the module with violent could damage the module and SFP module slot of the Managed

Switch.
