Mini-GBIC (SFP) Interface

Prepare a proper SFP module and install it into the optical trunk port. Then you can

connect ber optics cabling that uses LC connectors or SC connectors (with the use

of an optional SC-to-LC adapter) to the ber optics connector on the uplink port.

Fiber optics cable with LC duplex connector

Connecting optical ber to the trunk port

Warning

Never look directly at the transmitting ports of optical interface that

might be emitting laser, in order to prevent damage to the eye

from the laser radiation.

RJ-45 Electrical Interface

The pin assignment of RJ-45 connector on the Uplink port is shown in the following

gure and table.

1,2 T/Rx+,T/Rx-

3,6 T/Rx+,T/Rx-

4,5 T/Rx+,T/Rx-

7,8 T/Rx+,T/Rx-
