5. Application
5.1 GEPON Applications
The OLT device is deployed in the central ofce room. The ONU devices are
connected to the OLT device through an optical splitter, which forms a P2MP (Point-
to-Multipoint) topology, connect to the switches or the devices as computers, IP
Phone, IP Surveillance for Triple Play Service. Shown as below Figure.
High Rise Buildings
PC
Camera
IPTV
IP Phone
IPTV
VoIP
Internet
Campus
IP Surveillance Application
PON
PON
PON
EPN-102
GEPON OLT
EPN-102
EPN-104
1000Base-T UTP
100Base-TX UTP
PON
Passive Optical Network
Triple-Play Application
GEPON Applications
