4. Setup the GEPON OLT EPL-1000

The followings are instructions for setting up PLANET EPL-1000. Refer to the

illustration and follow the simple steps below to quickly install your GEPON OLT.

Pre-Installation

This section provides the information users have to ware before installing the EPL-

1000. The information includes required installation tools, safety requirements, and

electrostatic discharge protection.

Tools and Test Equipment Requirements

To install and maintain the EPL-1000, you should have the tools and test equipment

listed in the Table 4-1.

Table 4‑1 Required Installation Tools and Materials

Item Required Purpose

Anti-static wrist strap

Protect the EPL-1000 system from electrostatic

discharge damage.

Hand tools

Screw drivers for equipment removal and

replacement.

Wire cutter/stripper Prepare wires for electrical connections.

Accessories and hardware kit

Screws, bolts, etc., for securing the equipment

on the desired location.

Safety Requirement

To prevent possible serious injury, do not apply power to the EPL-1000 system until

you’ve completed all of the installation procedures and connected it to the external

facilities. Be cautious, when turning on/off the EPL-1000 system power.

4.1 Hardware Installation

The PLANET EPL-1000 is a 1U high box-type GEPON OLT with rack-mountable

enclosure. It can be installed in a standard 19-inch rack by using the mounting

brackets provided. Mount the shelf on the rack using the large screws provided.

The procedure to connect and wire the system is as follows.
