EPL-1000 GUI Personality Setup

The EPL-1000 supports a 10/100Mb Management interface for User-Friendly

GUI Management. Prior to installing the GUI, it may be necessary to modify the

Host and Management IP addresses conguration stored in the OLT personality

ash. It can either be left as the defaults or changed to suit your own network

environment.

You can see what the current settings are by typing the following commands.

Commands shown below must be entered at the Tera Term command prompt for

the EPL-1000.

1) 3721/>pers [Enter]

2) 3721/pers/>show [Enter]

This will result in information about the state of the personality ash being

displayed. The items near the end of the prints are the current Management

Interface Settings. Typically the factory settings are:

Management interface settings:

Physical interface: ethernet

Management VLAN: 4095

Transport protocol: udp

Local IP cong: static

Host IP cong: static

Host IP: 192.168.1.100

Mgmt IP: 192.168.1.101

Netmask: 255.255.255.0

The Mgmt IP address refers to the IP address of the OLT 10/100Mb MGMT Port.

The Host IP address refers to the IP address of the PC which is running the GUI

Utility. The default settings are for both of these IP addresses to be statically

assigned. The netmask should be set to suit the class of the IP addresses. In

addition to the 10/100Mb MGMT Port, management can also be performed in-band.

In this case the MGMT Port is not connected. Instead the OLT is programmed for

in-band management and the user sets the VID of the VLAN used for management.

The Transport protocol should always be set to UDP.

The following sections outline how to change the settings for each of the

management options.
