TF8200 A2+ BIOS Manual
24
5 Chipset Menu
T his submenu allows you to configure the speci fic featur es of the chipset installed on
your system. This chipset manage bus speeds and access to system memory
resources, such as DRAM. It also coordinates communications with the PCI bus.
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP U TILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Advanced Chipset Settings
WARNING: Setting wrong values in below sections
may cause system to malf unction.
iGPU and Ext-VGA Selection [Dis able iGPU if Ex]
iGPU Frame Buffer Detect [Aut o]
PCIE training [Onl y Gen1]
Iso Flow Control [Dis abled]
Hi Priority Channel [Ena bled]
Display Refresh [Ena bled]
Primary Graphics Adapter [PCI E VGA Card Firs]
iGPU Frame Buffer Size [64M B]
Exit
Options
PCI VGA Card First
Internal VGA First
PCIE VGA Card First
Primary Graphics Adapter
This item allows you to choose the primary graphics device.
Options: PCIE VGA Card First (Default) / Intern al VGA First / PCI VGA Card
First
iGPU and Ext-VGA Selection
T his item determines the working VGA device when there are two VGA devices
installed at the same time.
Options: Disable iGPU if Ext-VGA exist (Default) / Both Exist and iGPU by
Frame Buffer Det ect
