TF8200 A2+ BIOS Manual
26
6 T-Series Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you to use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP U TILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause system to malf unction.
=========== Automate OverClock Sy stem ===========
============ Manual OverClock Sys tem ============
OverClock Navigator [N ormal]
Integrated Memory Test [D isabled]
Auto OverClock System [V 6-Tech Engine]
CPU Frequency, MHz [2 00]
z
> Over-Voltage Configuration
> DRAM Timing Configuration
> Spread Spectrum Configuration
Processor Frequency Multiplier [A uto]
SB to K8(CPU) Freq Auto [E nabled]
SB to K8(CPU) LinkWidth [1 6 16 ]
Memory Clock Mode [A uto]
MCP PCI-Express Frequency, MH [1 00]
Exit
Options
Normal
Automate OverClock
Manual OverClock
OverClock Navigator
OverClock .Navigator is designed for beginners in overclock field.
Based on many test and experiments from Biostar Engineer Team, OverClock
Navigator provid es 3 default overclo ck con figur ations that are able to raise the
system performance.
Options: Normal (Default) / Automate OverClock / Manual OverClock
