TF8200 A2+ BIOS Manual
33
tRFC0 / tRFC1 / tRFC2 / tRFC3
Options: Auto (Default)
Spread Spectrum Configuration
BIOS SETUP U TILITY
T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Spread Spectrum Configuration
CPU/LDT Spread Spectrum [D isabled]
PCIE
SATA
iGPU
Spread Spectrum [D isabled]
Spread Spectrum [D isabled]
Spread Spectrum [D isabled]
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Options
Disabled
Enabled
CPU/LDT Spread Spectrum
This item allows you to control the CPU/LDT spread spectrum.
Options: Disabled (Default) / Enabled
PCIE Spread Spectrum
This item allows you to control the PCI-Express spread spectrum.
Options: Disabled (Default) / Enabled
SATA Spread Spectrum
This item allows you to control the SATA spread spectrum.
Options: Disabled (Default) / Enabled
iGPU Spread Spectrum
This item allows you to control the on-chip GPU spread spectrum.
Options: Disabled (Default) / Enabled
