TF8200 A2+ BIOS Manual

iGPU Frame Buffer Detect

This item allows you to control the iGPU frame buffer.

Options: Auto (Default) / Disabled

iGPU Frame Buffer Size

This item allows you to choose the frame bu ffer size of on-chip VGA.

Options: 64MB (Default) / 16MB / 32MB / 128MB / 256MB / Disabled

PCIE Traini ng

Options: Only Gen1 (Default) / Gen2 if supported

Iso Flow Control

Options: Disabled (Default) / Enabled

Hi Priority Channel

Options: Enabled (Default) / Disabled

Display Refresh

Options: Enabled (Default) / Disabled
