TF8200 A2+ BIOS Manual
34
CPU Frequency, MHz
This item allows you to select the CPU Frequency.
Options: 200 (MHz) (Default) / 100 ~ 500
Processor Frequency Multiplier
This item allows you to control the CPU multiplier.
Options: Auto (Default) / x4 ~ x25 (differs by CPU)
SB to K8(CPU) Freq Auto
Options: Enabled (Default) / Disabled
SB to K8(CPU) Frequency
Options: 1000MHz (Default) / 200 ~ 2600MHz
SB to K8(CPU) LinkWidth
Options: 16↓16↑ (Default) / 8↓8↑ / 4↓4↑
Memory Clock Mode
This item allows you to control the Memory Clock.
Options: Auto (Default) / Limit
MemClock Value
Options: 400MHz (Default) / 200 MHz / 266 MHz / 333 MHz / 533 MHz
MCP PCI-Express Frequency, MHz
Options: 100 (MHz) (Default) / 100 ~ 200
