TF8200 A2+ BIOS Manual
4
IDE Configuration
T he BIOS will automatically detect the presence of ID E/SAT A devices. There is a
sub-menu fo r each IDE/SAT A device. Select a device and press <Enter> to enter
the sub-menu of detailed options.
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
DISABLED: disables the
integrated IDE
Controller.
ENABLED: enables the
integrated IDE
Controller.
IDE Confuguration
OnChip S-ATA Controller [Enabled]
SATA Mode Select [SATA Mode]
> Primary IDE Master
> Primary IDE Slave
> SATA 1 Device
Hard Disk Write Protect [Disabled]
IDE Detect Time Out (Sec) [35]
Change the AHCI DID for Linux[Disabled]
> SATA 2 Device
> SATA 3 Device
> SATA 4 Device
OnChip P-ATA Controller [Enabled]
> SATA 5 Device
> SATA 6 Device
OnChip P-ATA Controller
This item allows you to control the onboard IDE controller.
Options: Enabled (Default) / Disabled
OnChip S-ATA Controller
This item allows you to control the onboard SATA controller.
Options: Enabled (Default) / Disabled
SATA Mode Select
This item allows you to choose the SATA operation mode. T o set SATA5/SATA6
device, please choose AHCI.
Options: SATA Mode (Default) / RAID / AHCI / Linux AHCI
Change the AHCI DID for Linux
This item appears only when SATA mode is set to Linux AHCI.
Options: Disabled (Default) / Enabled
