TF8200 A2+ BIOS Manual
37
CMOS Backup Function
It allows users to save different CMOS settings into BIOS-ROM and reload any
saved CMOS setting for customizing system configurations.
Moreover, users are able to save an ideal overclock setting during overclock
operation.
T here are 10 sets o f re cord address es in total, and users are able to nam e the CMOS
data acco rding to personal pre ferenc e.
BIOS SETUP U TILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Exit Options
ReloadCMOS Settings
Security Settings
Save Changes and Exit
Discard Changes and Exit
Discard Changes
Load Optimal Defaults
> Security
CMOS Backup Function
Exit
CMOS Backup Func
CMOS Data
CMOS Data Reload
Save
Security
This sub-menu allows you to provide/revise supervisor and user password.
BIOS SETUP U TILITY
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Install or Change the
password.
Security Settings
Supervisor Password :Not Installe d
User Password :Not Installe d
Change Supervisor Password
User Access Level [Ful l Access]
Change User Password
Clear User Password
Password Check [Set up]
Boot Sector Virus Protection [Dis abled]
Exit
