TF8200 A2+ BIOS Manual
35
Integrated Memory Test
Integrat ed Memory Test allows users to test memory module compatibilities without
additional device or software.
Step 1:
T his item is disabled on default; change it to “ Enable” to precede memory test.
BIOS SETUP U TILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause system to malf unction.
=========== Automate OverClock Sy stem ===========
============ Manual OverClock Sys tem ============
OverClock Navigator [N ormal]
Auto OverClock System [V 6-Tech Engine]
CPU Frequency, MHz [2 00]
z
> Over-Voltage Configuration
> DRAM Timing Configuration
> Spread Spectrum Configuration
Processor Frequency Multiplier [A uto]
SB to K8(CPU) Freq Auto [E nabled]
SB to K8(CPU) LinkWidth [1 6 16 ]
Memory Clock Mode [A uto]
MCP PCI-Express Frequency, MH [1 00]
Integrated Memory Test [E nabled]
Exit
Options
Normal
Automate OverClock
Manual OverClock
Step 2:
When the process is done, change the setting back from “Enabled” to “Disabled” to
complete the test.
BIOS SETUP U TILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause system to malf unction.
=========== Automate OverClock Sy stem ===========
============ Manual OverClock Sys tem ============
OverClock Navigator [N ormal]
Auto OverClock System [V 6-Tech Engine]
CPU Frequency, MHz [2 00]
z
> Over-Voltage Configuration
> DRAM Timing Configuration
> Spread Spectrum Configuration
Processor Frequency Multiplier [A uto]
SB to K8(CPU) Freq Auto [E nabled]
SB to K8(CPU) LinkWidth [1 6 16 ]
Memory Clock Mode [A uto]
MCP PCI-Express Frequency, MH [1 00]
Integrated Memory Test [D isabled]
Exit
Options
Normal
Automate OverClock
Manual OverClock
