TF8200 A2+ BIOS Manual
27
Auto OverClock System
BIOS SETUP U TILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause system to malf unction.
=========== Automate OverClock Sy stem ===========
============ Manual OverClock Sys tem ============
OverClock Navigator [A utomate OverClock]
Auto OverClock System [V 6-Tech Engine]
Integrated Memory Test [D isabled]
> Over-Voltage Configuration
> DRAM Timing Configuration
> Spread Spectrum Configuration
Processor Frequency Multiplier [A uto]
SB to K8(CPU) Freq Auto [E nabled]
SB to K8(CPU) LinkWidth [1 6 16 ]
Memory Clock Mode [A uto]
MCP PCI-Express Frequency, MH [1 00]
CPU Frequency, MHz [2 00]
z
Exit
Options
Normal
Automate OverClock
Manual OverClock
The Overclock Navig ator provides 3 different engines helping you to overclock your
system. These engines will boost your system performan ce to different level.
Options:
V6 Tech Engine
This engine will make a good over-clock performance.
V8 Tech Engine
This engine will make a better over-clock performance.
V12 Tech Engine
This engine will make a best over-clock performance.
Cautions:
1. Not every AMD CPU performs the above overclock setting ideally; the difference may vary
with the installed CPU model.
2. From BET experiment, the Atholon64 FX CPU is not suitable for this A.O.S. feature.
Содержание
