14
Prise en charge de 6 canaux.
Prise en charge de la microphone stereo.
Périphériques intégrés
a. Côté arrière
1 port série.
1 port parallèle (mode SPP/EPP/ECP)
1 port audio en position v erticale.
1 RJ-45 LAN Jack.
Souris PS/2 et clavier PS/2.
4 ports USB2.0.
b. Côté frontal
1 port disquette prenant en charge 2 FDD avec 360K, 720K, 1.2M, 1.44M et
2,88Mo.
4 ports USB2.0, 1 Embase Audio, 1 Embase de Sortie S/PDIF (optionnel).
Dimensions
Facteur de forme ATX : 19.5 cm x 29.3 cm. (W x L)
B. BIOS et logiciel
BIOS
Award legal Bios.
APM1.2.
ACPI.
Fonction USB.
Logiciel
Prise en charge de Warpspeeder
TM
, 9th Touc h
TM
, FLASHER™
Offrant la meilleure performance pour Windows 98 SE, Windows 2000, Windows Me,
Windows XP, UNI X series etc .
Contenu de l'Emballage
Câble de Disque Dur X1
Câble de Lecteur de Disquette X1
Manuel d’utilisation X1
Câble USB 2.0 X1 (Optionnel)
Panneau d’E/S Arrière pour Boîtier Flex X 1 (Optionnel)
CD de Pilote Complet X 1
Câble S/PDIF X1 (Optionnel)
