BIOS Setup
22
Modem Use IRQ
This determines the IRQ, which can be applied in MODEM use.
The Choices: 3 (default),4 / 5 / 7 / 9 / 10 / 11 / NA.
Run VGABIOS if S3 Resume
Choosing Enabled will make BIOS run VGA BIOS to in itialize the VGA card when system
wakes up from S3 state . The system time is shortened if you disable the function , but
system will need AGP driver to init ialize the card . So , if the AGP driver of the VGA card
does not support the initialization feature , the display may work abnormally or not function
after S3 .
The Choices: Auto, Yes (default), No.
Soft-Off by PWRBTN
Pressing the power button for more than 4 seconds forces the system to enter the
Soft-Off state when the system has “hung.”
The Choices: Delay 4 Sec, Instant-Off (default).
PWRON After PWR-Fail
This field determines the action the system will automatically take when power is
restored to a system that had lost power previously without any subsequent
manual intervention. There are 3 sources that provide current to the CMOS area
that retains these Power-On instructions; the motherboard battery (3V), the Power
Supply (5VSB), and the Power Supply (3.3V). While AC is not supplying power,
the motherboard uses the motherboard battery (3V). If AC power is supplied and
the Power Supply is not turned on, 5VSB from the Power Supply is used. When
the Power Supply is eventually turned on 3.3V from the Power Supply will be
used.
There are 3 options: “Former-Sts”, “On”, “Off”.
“Former-Sts” Means to maintain the last status of the CMOS when AC
power is lost.
“On” Means always set CMOS to the “On” status when AC
power is lost
“Off” (default) Means always set CMOS to the “Off” status when AC
power is lost.
For example: If set to “Former-Sts” and AC power is lost when system is live,
then after AC power is restored, the system will automatically power on. If AC
power is lost when system is not live, system will remain powered off.
IRQ/Event Activity Detect
If you highlight the literal “Press Enter” next to the “IRQ/Event Activity Detect” label
and then press the enter key, it will take you a submenu with the following options:
VGA
When set to On, any event occurring at a VGA Port will awaken a system which
