11
Front Panel Audio Header: JAUDIO1
1
14
13
2
JAUDIO1
Pin Assignment Pin Assignment
1
Left stereo Mic In/ Center
2
Ground
3
Right stereo Mic In/ Bass
4
Audio Power
5 Right Line Out/ Speaker Out
Right
6 Right Line Out/ Speaker Out Righ
t
7
Reserv ed
8
Key
9
Left Line Out/ Speaker Out
Left
10
Left Line Out/ Speaker Out Left
11
Right Line In/ Rear Speaker
Right
12
Right Line In/ Rear Speaker Right
13
Left Line In/ Rear Speaker Left
14
Left Line In/ Rear Speaker Left
Front USB Header: JUSB2/ JUSB3
Pin Assignment Pin Assignment
1 +5V 2 +5V
3
USB-
4
USB-
5
USB+
6
USB+
7
Ground
8
Ground
1
10
9
2
JUSB2/
(JUSB3)
9
KEY
10
NA
Frequency Selection: JCLK1
Pin 100 MHz 133 MHz 166 MHz 200 MHz
1-2
Open Open Close Open
3-4
Close Close Close Open
5-6
Close Open Open Open
1
2
87
7-8
Open Close Close Open
