Features
A. Har dware
CPU
Prov ides Soc k et A.
Supports single AMD
®
Athlon XP/ Duron Family processor.
Front Side Bus at 200/266/333/400 MHz.
Chipset
North Bridge: VIA KT600.
South Bridge: VIA VT8237.
Main Memory
Supports up to 2 DDR devices.
Supports 266/333/400 MHz (without ECC) DDR devices.
Maximum memory size is 2GB.
Super I/O
Chip: U2 ITE8705F.
Prov ides the most commonly used legacy Super I/O functionality.
Env ironm ent C ontrol init iativ es,
- H/W Monitor
- ITE's “Smart Guardian” function
Slots
Five 32-bit PCI bus master slots.
One AGP 4X/8X compatible slot.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Master Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
LAN
PHY: VIA VT6103.
Supports 10 Mb/s and 100 Mb/s auto-negotiation
Half /Full duplex c apability.
On Board AC’97 Sound Codec
Chip: CMI9761A.
Compliant with AC’97 specification.
Supports 6 channels.
Supports stereo Microphone.
