Biostar M7VIT 800 [48/57] Bios setup

BIOS Setup

EPP Usin g P aralle l Port as Enhanced P aralle l Port.

ECP Usin g P aralle l port as Extended Capabilities Port.

ECP+EPP Usin g P aralle l port as ECP & EPP mode.

ECP Mode Use DMA

Select a DMA Channel for the port.

The Choices: 3 (default), 1.

Init Display First

With systems that have multiple video cards, this option determines whether the primary

display uses a PCI Slot or an AGP Slot.

The Choices: PCI Slot (default), AGP.
