NF61S Micro 754 BIOS Setup

PCIE/SATA Spread Spectrum

This item allows you to enable/disable the Spread Spectrum function.

The Choices: Disabled (default), Triangular Down.

HT Spread Spectrum

This item allows you to select HT Spread Spectrum function.

The Choices: Disabled (default), 0.50% H.Kiss Cntr, 0.75% H.Kiss Cntr,

0.50% Triang. Center, 0.75% Triang. Center

SSE/SSE2 Instructions

This item allows you to enable/disable SSE/SSE2 instruction.

The Choices: Enabled (default), Disabled.

System BIOS Cacheable

Selecting the “ Enabled” option allows caching of the system BIOS ROM at

F0000h-FFFFFh, which is able to improve the system performance. However,

any programs that attempts to write to this memory block will cause conflicts

and result in system errors.

The Choices: Disabled (default), Enabled.
