NF61S Micro 754 BIOS Setup

POWER ON Function

This item allows you to choose the power on method.

The Choices: Button Only (default), Password, Hot Key, Mouse Move/Click,

Mouse Double Click, Any Key, Keyboard 98.

KB Power ON Password

Input password and press Enter to set the Keyboard power on password.

Hot Key Pow er ON

Choose the Hot Key combination to boot up the system.

The Choices: Ctrl-F1(default), Ctrl-F2, Ctrl-F3, Ctrl-F4, Ctrl-F5, Ctrl-F6,

Ctrl-F7, Ctrl-F8, Ctrl-F9, Ctrl-F10, Ctrl-F11, and Ctrl-F12.

POWER After PW R- Fail

This setting specifies how your system should behave after a power fail or

interrupts occurs. By choosing off will leave the computer in the power off state.

Choosing On will reboot the computer. Former-Sts will restore the system to the

status before power failure or interrupt occurs.

The Choices: Off (default), On, Former-Sts.
