Biostar T-Series TForce 6100
User’s Manual
49
Conectores y ranuras integrados e internos
1 ranura 1X PCI-Express
1 ranura 16X PCI-Express
1 conector de salida S/PDIF
1 conector de entrada de audio en CD-ROM
2 ranuras PCI
2 puertos Serial ATA II
2 conectores Ultra DMA 33/66/100/133 IDE
Back Conectores de E/S del panel posterior
4 puertos USB 2.0
1 puertos VGA
1 puertos Serial
1 puerto impresora
1 conector de red LAN RJ-45
1 puerto para ratón PS/2
1 puerto para teclado PS/2
1 puerto de audio vertical que incluye un conector de
entrada de línea, un conector de salida de línea y un
conector de entrada de micrófono.
