TForce 6100-939 & TForce 6100
19
Onboard Serial Port 2
Select an address and corresponding interrupt for the first and second serial ports.
The Choices: Disabled (default), 2F8/IRQ3, 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3,
Auto.
UART Mode Select
This item allows you to determine which Infra Red (IR) function of onboard
I/O chip.
The Cho ices: Normal, AS KIR, IrDA (default) .
UR2 D uple x Mo de
Select the value required by the IR device connected to the IR port.
Full-duplex mode permits simultaneous two-direction transmission.
Half-duplex mode permits transmission in one direction only at a time.
Th e Ch o ice s : Ha lf (default), Full.
Onboard Parallel Port
This item allows you to determine access onboard parallel port controller
with which I/O Address.
The Choices: 378/IRQ7 (default), 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
The default value is SPP.
The Choices:
SPP(default) Usin g Parallel port as Standard Printer P ort.
EPP Using Parallel Port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port.
ECP+EPP Using Parallel port as ECP & EPP mode.
ECP Mode Use DM A
Select a DMA Channel for the port.
The Choices: 3 (default), 1.
OnChip USB
This option should be enabled if your system has a USB installed on the
system board. You will need to disable this feature if you add a higher
performance controller.
The Choices: V1. 1+V2. 0 (default), Disabled, V1.1
USB Me mo ry T ype
The Choices: SHADOW (default), Base Memory(640K).
USB keyboard Support
Enables support for USB attached keyboard.
The Choices: Disabled, Enabled (default).
