Biostar T-Series TForce 6100
User’s Manual
59
内部オンボードスロットとコネクタ
PCI-Express x1 スロット(x1)
PCI-Express x16 スロット(x1)
S/PDIF アウトコネクタ(x1)
CD-ROM オーディオインコネクタ(x1)
PCI スロット(x2)
シリアル ATA II ポート(x2)。
Ultra DMA 33/66/100/133 IDE コネクタ(x2)
背面パネル I/O コネクタ
USB 2.0 ポート(x4)
VGA ポート (x1)
プリンター ポート (x1)
シリアルポート(x1)
RJ-45 LAN ジャック(x1)
PS/2 マウスポート(x1)
PS/2 キーボードポート(x1)
ラインイン コネクタ 1つ、ラインアウト コネクタ 1つ、
および MIC イン
コネクタを含む縦型オーディオ ポート 1つ。
05/18, 2006
