Biostar T-Series TForce 6100
User’s Manual
7
C. Dual Channel Memory installation
To trigger the Dual Channel function of the motherboard, the
memory module must meet the following requirements:
Install memory module of the same density in pairs, shown in
the following table.
Duual Channel Status
DIMM1
DIMM2 DIMM3 DIMM4
Enabled O X O X
Enabled X O X O
Enabled O O O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same
(x8 or x16).
