2 Advanced Menu | 11
A68N-5745 / A68N-5545 / A68N-5600
Specic Key
This item will show only when Keyboard PowerOn is set “Specic Key.” Press Enter to set Specic
key.
PS2 Mouse PowerOn
This item allows you to control the mouse power on funcon.
Opons: Disabled (Default) / Enabled
USB Device Wakeup from S3/S4
This item allows you to enable or disabled the USB resume from S3/S4 funcon.
Opons: Disabled (Default) / Enabled
CPU Configuration
This item shows CPU Informaon
Power Now
This item allows you to enable or disable the generaon of ACPI _PPC, _PSS, and _PCT objects.
Opons: Enabled (Default) / Disabled
NX Mode
This item allows you to enable or disable No-execute page protecon Funcon
Opons: Enabled (Default) / Disabled
SVM Mode
This item allows you to enable AMD virtualizaon in CPU.
Opons: Enabled (Default) / Disabled
CPB Mode
This item allows you to species the method of core performance boost enablement.
Opons: Auto (Default) / Disabled
C6 Mode
This item allows you to enable or disable C6.
Opons: Enabled (Default) / Disabled
