Biostar A68N-5600 Версия 6.4 [20/32] Gfx configuration
![Biostar A68N-5600 Версия 6.4 [20/32] Gfx configuration](/views2/1712345/page20/bg14.png)
20 | 3 Chipset Menu
GFX Conguraon
Primary Video Device
This item allows you to select Primary Video Device that BIOS will use to for output.
Opons: NB PCIe slot Video (Default) / IGD Video
Integrated Graphics
This item set integrated graphics controller.
Opons: Auto (Default) / Disabled / Force
»
Note: The following items appear only when you set the Integrated Graphics item to [Force]
UMA Frame Buer Size
This item set UMA FB Size.
Opons: 256M (Default) / 32M / 64M / 128M / 512M / 1G / 2G
GFX HD Audio Controller
This item allows you to set GFX HD Audio controller.
Opons: Enabled (Default) / Disabled
PSPP Policy
This item allows you to set PCIe speed power policy.
Opons: Balanced-High (Default) / Disabled / Performance / Balanced-Low / Power Saving
Surround View
This item supports mul-display funcon.
Opons: Disabled (Default) / Enabled
FB Locaon
This item allows you to set FB Locaon
Opons: Above 4G (Default) / Below 4G
