Planet ISW-802M [11/60] Status
![Planet ISW-802M [11/60] Status](/views2/1071785/page11/bgb.png)
Off No device attached
Yellow The port is operating in full-duplex mode.
Blinks Collision of Packets occurs in the port.
FDX/COL
(Port 7 & 8)
Off The port in half-duplex mode or no device attached
2.1.4 Reset Button
The reset button provides user a quick and easy way to restart and set the configuration back to default
value.
。 Restart: press the button for 2 seconds and release.
。 Set to factory default value: press the button for 5 seconds and release. The switch
will set all configurations back to default setting.
2.1.5 DIP Switches
The switch provides the 9 DIP-switch for configuring the relay alarm operation mode and the ring master
operation mode. The default value of Dipswitch is OFF.
DIP Switch No
Status Description
OFF Disable port 1 Alarm
1
ON
Enable port 1 Alarm. If the port’s link fails, the fault LED will
light up.
OFF Disable port 2 Alarm
2
ON
Enable port 2 Alarm. If the port’s link fails, the fault LED will
light up.
OFF Disable port 3 Alarm
3
ON
Enable port 3 Alarm. If the port’s link fails, the fault LED will
light up.
OFF Disable port 4 Alarm
4
ON
Enable port 4 Alarm. If the port’s link fails, the fault LED will
light up.
OFF Disable port 5 Alarm
5
ON
Enable port 5 Alarm. If the port’s link fails, the fault LED will
light up.
6
OFF Disable port 6 Alarm
