100Base-FX 2 (mm, sc)
Protocol CSMA/CD
Switching Architecture Store and forward
Transfer Rate 144,880 pps for Ethernet port and 1448,800 pps for Fast Ethernet port
MAC address 2K
Memory Buffer 1Mbit
Network Cable 10Base-T : 2-pair UTP/STP Cat 3, 4, 5 cable
100Base-TX: 2-pair UTP/STP Cat. 5 cable
10Base-T: EIA/TIA-568 100-ohm (100m)
Optical Cable
SC (Multi-mode): 50/125µm to 62.5/125µm
Available distance: 2KM, Wavelength: 1310nm
LED Per port: Link/Activity (Green), Full duplex/Collision (Yellow)
Per unit: Power (Green), Power 1 (Green), Power 2 (Green), Fault (Yellow),
Ring Master (Green)
Back-plane 1.6Gbps
Packet throughput ability 1.19Mpps@64bytes
Power Supply 12 to 48 V DC, Redundant power with polarity reverse protection function
Power Consumption 4.6 Watts
Installation Provide DIN rail kit and wall mount plate for 3-way installation
Operating environment 0 to 60 Degree C, 5% to 90%RH (Non-condensing)
Storage environment -40 to 85 Degree C, 5% to 90%RH (Non-condensing)
Dimension (W x D x H) 54 × 105 × 155 mm
Emission FCC Class A, CE mark
Stability testing IEC60068-2-32(Free fall), IEC60068-2-27(Shock), IEC60068-2-6(Vibration)
Management
Management Interface Web, SNMP v1,v2c, v3
SNMP MIB RFC 1213 MIBII, RFC 1493 Bridge MIB, RMON RFC 1757, RFC 2674
VLAN MIB, RFC 1643 Ethernet like MIB, RFC1215 Trap MIB, IGMP MIB.
Private MIB for switch information, super ring, port alarm, TFTP firmware
upgrade, reset, port mirror, IP security.
SNMP Trap Up to 3 Trap stations.
Cold start, Port link Up, Port link down, Authentication Failure, Private Trap
for power status, Port Alarm configuration, Fault alarm, super ring.
Management IP security Support IP address security to prevent unauthorized intruder.
Firmware update Support TFTP firmware update, TFTP configuration backup and restore.
System event log Provides 1000 event log entries.
Alarm Provides one relay output for port breakdown, power fail and provide DIP
switch to mask link down port.
Alarm Relay current carry ability: 1A @ DC24V
DHCP client Provide DHCP client function to obtain IP address from DHCP serve.
Switching
Redundant ring 2 ports for super ring to provide redundant backup feature and the recovery
time below 300ms. It also supports coupling ring function. Ring and coupling
port configure by web interface and ringmaster by hardware DIP switch.
VLAN Supports port-based VLAN and IEEE802.1Q Tag VLAN.
Both of port based and Tag based VLAN group up to 64 VLANs.
Class of service IEEE802.1p class of service support, per port provides 4 priority queues.
Quality of service The quality of service support port based, Tag based and IPv4 Type of
