service.
IGMP Support IGMP v1 and Query mode. Up to 256 groups.
Spanning tree IEEE802.1d spanning tree and IEEE802.1w rapid spanning tree.
SNTP Support simple network time protocol.
SMTP Support simple mail transfer protocol.
Bandwidth control Support ingress packet filter and egress packet limit.
The egress rate control supports all of packet type and the limit rates are
128kbps, 256Kbps, 512Kbps, 1MB, 2MB, 4MB, and 8MB.
Ingress filter packet type combination rules are
Broadcast/Multicast/Unknown Unicast packet, Broadcast/Multicast packet,
Broadcast packet only and all of packet. The packet filter rate can be set
follow as:1Mbps、2Mbps、4Mbps、8Mbps、16Mbps、32Mbps、64Mbps.
Port mirror Support TX packet only or both of TX and RX packet.
Packet filter
4 selection rules for different type of packet combination:
1. All of packet
2. Broadcast/ multicast/ unknown unicast packet
3. Broadcast/ multicast packet
4. Broadcast packet only
Network Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE802.3x Flow Control and Back-pressure
IEEE802.1d spanning tree / IEEE802.1w rapid spanning tree
IEEE802.1p class of service
IEEE802.1Q VLAN Tag
