55 ANTENNA ANT CONNECTOR This is used to connect an antenna to the set Its imped ance is 50 ohms and connect with a PL 259 connector 66 ACCESSORY ACC SOCKET Various functions are available through the accessory socket such as modulation output receiver output T R changeover and so forth The table below shows those terminals 56 KEY JACK For CW operation connect a key here using a standard 1 4 inch plug For electronic keying the terminal voltage must be less than 0 4V DC ACC SOCKET CONNECTIONS 57 EXTERNAL SPEAKER JACK When an external speaker is used connect it to this jack Use a speaker with an impedance of 8 ohms When the external speaker is connected the built in speaker does not function Outside view PIN No 58 EXTERNAL ALC TERMINAL This terminal can be used for input terminal of external ALC signal from a linear amplifier or transverter The ALC voltage should be in 0V 4V 1 Output from the squelch control stage 8V when the squelch is ON 2 13 8 Volts DC in conjunction with the power switch operation Connected to Push to talk T R change over switch When grounded the set operates in the transmit mode Output from the receive detector stage Fixed output regardless of AF output or AF gain Output from Transmitter MIC amplifier stage Input for MIC gain control stage 8 Volts DC available when transmitting relay can not be directly actuated Max 5mA Input for external ALC voltage Ground Input for RTTY keying MARK HIGH level SPACE LOW level NC No Connection Input for TRANSVERTER control When 8 Volts DC is applied the set can operate with a transverter Output reference voltage for band switching Output for external band switching NC 3 59 T R CONTROL TERMINAL Controls Transmit Receive for an external linear amplifier or transverter This terminal can be used to switch 24V 1A DC Don t exceed this limit 60 RECEIVER INPUT TERMINAL This is an input terminal which is connected directly to the receiver 6 61 RECEIVER ANTENNA OUTPUT TERMINAL This is a terminal to which received signals from the anten na connector are conducted after the signal passes through the transmit receive antenna switching circuit Usually the receiver IN and OUT terminals are jumpered The receiver antenna output terminal is usually used when another receiver is used or a preamplifier is connected to the IC 751 9 7 10 11 12 13 14 24 62 SPARE TERMINAL This terminal is available for your personal use such as for adding accessory circuit etc if desired FUNCTION 67 OPTIONAL INTERFACE UNIT CONNECTOR POSITION This is provided to install the DP 25 connector of the optional interface unit 63 TRANSVERTER TERMINAL VHF and UHF operation using a suitable transverter with the IC 751 is possible This terminal is for Transverter connection The output is about 30mV 68 OPTIONAL BUILT IN AC POWER SUPPLY SOCKET POSITION This is provided to install AC power socket plate of the optional built in AC power supply IC PS35 64 GROUND TERMINAL To prevent electrical shock TVI BQI and other problems be sure to ground the equipment through the GROUND TERMINAL For best results use as heavy a gauge wire or strap as possible and make the connection as short as possible even in mobile installations 65 DC POWER SOCKET For connection of the IC PS15 s DC power cord or other suitable power supply 11
