Pushing the XIT switch to turn ON the XIT USB Pushing the DFS switch and turning the TUNING CONTROL RIT XIT Ü0CTÜ I C Cl 1 Cl 3 1 VFO A Receiving and transmitting on 14 263 9MHz USB VFO A To turn OFF the XIT function push again the XIT switch and the letters XIT and shifted frequency displayed on the frequency display are no longer displayed If the RIT is ON the shifted frequency will remain When the XIT circuit is OFF the transmit and receive frequencies are the same regardless of the shifted frequency However the shifted frequency is stored in the memory and it will be reappear when the XIT switch is pushed again 1 0 By pushing the MEMORY WRITE button the frequency and mode are memorized into the MEMORY CHANNEL 27 FOR EXAMPLE Now you are operating on 14 271 MHz USB and memory channel 7 memorizes 29 625MHz and FM If you wish to operate with the frequency and modes which are memorized in the memory channel 7 push the DFS switch in and turn the tuning control to be displayed memory channel number 7 Then push the FREQUENCY TRANSFER button and 29 625 0 and FM are ap peared on the frequency display Now you can operate on these frequency and modes and by pushing and releasing the DFS switch the displayed frequency can be changed by turning the tuning control Pushing the XIT switch to turn OFF the XIT Pushing the XIT switch again to turn ON the XIT To clear the shifted frequency or to add the shifted fre quency to the displayed one you can make it in like manner as the RIT 5 1 12 DIAL FUNCTION SELECT SWITCH IN VFO MODE In the VFO mode by pushing the DFS DIAL FUNCTION SELECT switch in the operating frequency locked on the displayed frequency and by turning the TUNING CON TROL the MEMORY CHANNEL NUMBER displayed on the frequency display can be changed This is very con venient to memorize the operating frequency and modes into a memory channel or to change the operating fre quency and modes to ones in a memory channel Pushing the DFS switch and turning the TUNING CONTROL USB I UJ1 I C I n I LI n u VFO A Pushing the FREQUENCY TRANSFER button FOR EXAMPLE Now you are operating on 14 271 MHz and USB and memory channel number 7 is displayed If you want to memorize these into the memory channel 27 push the DFS switch in and you can change the displayed memory channel number by turning the tuning control Turn the tuning control to obtain the desired memory channel number at this time 27 then push the MEMORY WRITE button and the operating frequency 14 271 MHz and mode USB afe memorized into the memory channel 27 To change the operating frequency again push and release the DFS switch The contents of the channel 7 are p O l C n transferred to the VFOA V FO A 5 2 MEMORY CHANNEL OPERATION 5 2 1 MEMORY CHANNEL SELECTION When the power switch is turned ON the set initially operates with the VFO A and memory channel number 01 is displayed By pushing the VFO MEMORY switch the set is switched into the MEMORY CHANNEL MODE and frequency mode and HAM GENE mode which have been stored in the MEMORY CHANNEL 1 are displayed On the display 17
