using a tape recorder connected to the headphone jack With a stereo headphone set inserted this way however the headphone will lose the sound on one side With the plug inserted completely only the headphone works of the final stage The fan operates as follows 1 The fan does not operate both in the receive and thansmit modes 2 When the temperature rises to a point 50 C detected by the monitor curcuit the fan will operate during both transmit and receive to provide additional cooling 3 If the temperature rises to a danger limit 90 C the fan will run much more rapidly At this time the output power is reduced to 50 Watts Investigate the cause of overheating i e antenna mismatch etc and correct the cause of the overheating before starting to transmit again 3 11 COOLING FAN The rear of the PA unit is designed to provide for adequate cooling but with 200 Watts input the final stage produces quite a bit of heat and its temperature may rise during prolonged transmissions The fan is connected to a tem perature monitoring circuit which monitors the temperature SECTION 4 OPERATING CONTROLS 4 1 FRONT PANEL TRANSMIT INDICATOR 0 MULTI FUNCTION METER RECEIVE INDICATOR NARROW INDICATOR FREQUENCY DISPLAY VFO MEMORY SWITCH VFO SWITCH VFO EQUALIZING SWITCH MODE SELECT SWITCHES FUNCTION KEY INDICATOR 0 FUNCTION KEY NB LEVEL CONTROL NB TIMING SWITCH MONITOR SWITCH COMP SWITCH DUPLEX SPLIT SWITCH MEMORY WRITE BUTTON FREQUENCY TRANSFER BUTTON I INCREMENTAL TUNING CONTROL RIT SWITCH VOX GAIN CONTROL VOX DELAY CONTROL POWER SWITCH AGC SWITCH T R SWITCH METER SWITCH XIT SWITCH RIT XIT CLEAR BUTTON MIC CONNECTOR FILTER SWITCH PHONES JACK NOTCH FILTER SWITCH AF GAIN CONTROL PBT CONTROL RF GAIN CONTROL HAM GENERAL COVER SELECT SWITCH SQUELCH CONTROL NOTCH FILTER CONTROL TUNING RATE TONE CONTROL SWITCH SPEECH SYNTHESIZER SWITCH L MODE SELECTIVE SCAN SWITCH MIC RF GAIN POWER CONTROL CONTROL BAND SELECT FUNCTION SWITCH DIAL FUNCTION SELECT SWITCH SCAN START STOP BUTTON TUNING CONTROL DIAL LOCK SWITCH 5
