SECTION 1 SPECIFICATIONS GENERAL Harmonic Output More than 40dB below peak power output Spurious Output More than 60dB below peak power output Carrier Suppression More than 40dB below peak power output Unwanted Sideband More than 55dB down at 1000Hz AF input Microphone Impedance 600 ohms Input Level 12 millivolts typical Dynamic or Electret Condenser Microphone Optional IC HM12 or IC SM6 can be used Number of Semiconductors Transistors 105 FET 16 IC Includes CPU 51 Diodes 219 Frequency Coverage 2 0MHz Ham Band 1 8 MHz 3 45MHz 4 1MHz 6 95MHz 7 5MHz 9 95MHz 10 5MHz 13 95MHz 14 5MHz 17 95MHz 18 5MHz 20 95MHz 21 5MHz 24 45MHz 25 1MHz 27 95MHz 30 0MHz General Cover Receive Only 0 1MHz 30 0MHz Thirty 1MHz Segments or Continuous RIT XIT Coverage 9 9KHz Frequency Control CPU based 10Hz step Digital PLL synthesizer Independent Transmit Receive Frequency Available on same band Frequency Readout 6 digit 100Hz readout Frequency Stability Less than 200Hz after switch on 1 min to 60 mins and less than 30Hz after 1 hour Less than 500Hz in the range of 0 C 50 C Power Supply Requirements DC 13 8V 15 Negative ground Current drain 20A max at 200W input AC power supply is available for AC operation Antenna Impedance 50 ohms Unbalanced Weight 8 5Kg Dimensions 115mm H x 306mm W x 355mm D RECEIVER Receiving System SSB CW RTTY AM Quadruple Conversion Superheterodyne with continuous Bandwidth Control FM Triple Conversion Superheterodyne Receiving Mode Alr A3J USB LSB Fi Output FSK audio signal A3 F3 IF Frequencies 1st 70 4515MHz 2nd 9 0115MHz SSB 9 0106MHz CW RTTY 9 0100MHz AM FM 3rd 455KHz 4th 350KHz except FM with continuous Bandwidth Control Sensitivity SSB CW RTTY 0 1 0 5MHz Less than 0 5MV for 10dB S N 1 0MV for 10dBS N 0 5 1 6MHz Less than 1 6 30MHz Less than 0 1 5MV for 10dB S N 3MV for10dBS N 0 5MHz Less than AM 0 1 6MV for10dBS N 0 5 1 6MHz Less than 1MV for10dBS N 1 6 30MHz Less than FM 1 6 30MHz Less than 3MV for 12dB SIN AD Squelch Sensitivity 1 6 30MHz Less than 0 3 zV Selectivity SSB CW RTTY 1 15KHz Adjustable to 0 4KHz Min at 6dB 2 0KHz at 60dB AM 1 2KHz at 6dB 2 25KHz at 60dB When Filter switch ON 2 0KHz at 6dB 7 5KHz at 60dB FM 7 5KHz at 6dB 15KHz at 60dB Notch Filter Attenuation More than 45dB Spurious Response Rejection Ratio More than 60dB Audio Output More than 3 Watts Audio Output Impedance 8 ohms TRANSMITTER RF Power SSB A3 J 200 Watts PEP inputf CW A RTTY Fi 200 Watts input FM F3 200 Watts input AM A3 40 Watts output Continuously Adjustable Output power 10 Watts Max Emission Mode SSB Upper sideband and Lower sideband A3J CW At RTTY Frequency Shift Keying Fi AM A3 FM F3 Specifications are approximate and are subject to change without notice or obligation 1
