3 4 ANTENNA Antennas play a very important role in radio communi cation If the antenna is inferior your transceiver cannot give you the best performance With a good antenna and feeder cable having 50 ohms impedance you should easily get the desired matching and performance Carefully install a high performance antenna that suits the frequency band s you wish to operate on and place it as high as possible Be especially careful of the condition of the connectors as loose connections will deteriorate the performance Be sure to connect the ground terminal of a whip antenna if used to the body of your car As the output is quite high avoid connecting the antenna connector to open lines and do not transmit under mis matched conditions Otherwise the final stage could be overloaded and cause a malfunction of the unit 3 8 CW KEY When operating CW connect a key to the KEY jack on the rear panel with the key plug supplied 1 4 inches standard plug The connection of the plug is shown below Since the IC 751 has a General Coverage receiver it is recommended that a long wire general coverage antenna and an antenna coupler be used The antenna s impedance should be 50 ohms To attempt to use the Ham band antenna for general coverage reception could result in mismatching and attendant poor reception 3 5 GROUND In order to prevent electrical shocks TV I BCI and other problems be sure to connect a heavy wire ground as short as possible from a good earth point to the ground terminal on the rear panel 3 6 MICROPHONE The optional electret condenser type hand microphone IC HM12 or stand microphone IC SM6 can be used Merely plug it into the proper receptacle on the front panel Should you wish to use a different microphone make certain it has proper output level Particular care should be excercised in wiring also as the internal electrical switching system is dependent upon it Refer the schematics for the proper hookup If the terminals have polarity be sure to make the correct connection Note that the keyed voltage when switching with semiconductors or relays with resistors in the circuit should be adjusted to be below 0 4 Volts 3 8 RTTY When operating RTTY connect the ACC socket pins 8 ground and 9 to your tele typewriter through a high speed relay or a level converter to TTL level and the tones for your terminal unit will be available from pin 4 The AF output level is about 300mVp p for S 9 signal For details refer to 5 7 RTTY OPERATION on page 24 3 9 EXTERNAL SPEAKER The IC 751 contains an internal speaker and is also designed so that it can drive an external speaker from the external EXT speaker jack on the rear panel Be sure the impedance of the external speaker is 8 ohms and remember that with the external speaker connected the internal speaker is disabled 3 10 HEADPHONES Any good headphone set including stereo type that have 4 16 ohms impedance can be used With the plug inserted halfway into the PHONES jack both the headphone and speaker will operate This is convenient when others wish to listen in on the station or you wish to record contacts 4
