If you wish to transfer this operating frequency 14 295 MHz and mode USB into a VFO push the FREQUENCY TRANSFER button and the operating frequency 14 295 MHz and mode USB are transferred into the VFO pre viously selected NOTE Frequency mode and HAM GENE mode to be memorized Pushing the DFS switch in and turning the TUNING CONTROL Don t push the VFO MEMORY switch before pushing the FREQUENCY TRANSFER button to transfer the operating frequency at this time 14 295MHz or the operating frequency is erased and the original memorized frequency 14 271 MHz will be transferred into the VFO Pushing the VFO MEMORY switch to check contents of the channel Pushing the VFO MEMORY switch to return to the VFO then pushing the MEMORY WRITE button If you wish to rewrite the memorized frequency in the selected channel at this time 07 to this frequency 14 295 0 push the MEMORY WRITE button and the operating frequency 14 295MHz and mode USB are memorized into the memory channel 7 To change the operating memory channel again push and release the DFS switch then turn the TUNING CONTROL 5 2 3 MEMORY WRITE PROGRAMMING THE MEMORY CHANNELS Any operating frequency mode and HAM GENE mode can be memorized into a memory channel This is displayed after pushing the VFO MEMORY switch 5 2 4 MEMORY CLEARING If you want to clear contents of a memory channel the first select the channel to be cleared the second push the FUNCTION KEY then the MEMORY WRITE or FRE QUENCY TRANSFER button The contents of the channel will be cleared 1 Set the operating frequency mode and HAM GENE mode to desired ones by a VFO For example set them for 15 725MHz AM and GENE by using VFO B 2 Push the DFS switch in then select a memory channel to be memorized by turning the TUNING CONTROL For example select it at memory channel 10 3 To check the contents in the memory channel push the VFO MEMORY switch and the contents are displayed on the frequency display If you don t like to rewrite these contents select another memory channel which has contents erasable or no memorized frequency When no frequency h s been memorized only the MHz and KHz decimals are displayed at the frequency posi tion After checking push the VFO MEMORY switch again to return to the VFO Pushing the FUNCTION KEY first then the MEMORY WRITE or FREQUENCY TRANSFER button USB GENE 4 One push of the MEMORY WRITE button erases the previous memorized contents if any and memorizes the displayed frequency mode an HAM GENE mode into the selected memory channel at this time channel 10 5 3 TUNING BY UP DOWN THE MICROPHONE BUTTONS ON 5 3 1 FREQUENCY CONTROL With each push of the UP or DN down button on the optional microphone the operating frequency is changed one increment up or down respectively In the same way by depressing the button continuously the operating fre quency is changed up or down the same as turning the TUNING CONTROL The tuning rate is according to the setting of the TUNING RATE switch 5 Memorize other desired frequencies and so on into memory channels in the same manner Memory channel 1 and 2 are used also for the PROGRAMMED SCAN For PROGRAMMED SCAN operation refer to SCANNING OPERATION on page 20 19
