SECTION 2 FEATURES ALL BAND ALL MODE ALL SOLID STATE The IC 751 covers all the Amateur HF frequencies from 1 8MHz to 29 9999MHz including the new three bands of 10MHz 18MHz and 24MHz It offers not only SSB but also CW AM FM and RTTY All of the circuits in the IC 751 including the driver and final power stages are completely solid state and provide about 100 watts output GENERAL COVERAGE RECEIVER CAPABILITY The IC 751 has capabilities for an all amateur band transceiver as well as a general coverage receiver between 100KHz and 30MHz with continuous tuning The Up conversion system using a high side IF and Microcomputer Control System make these capabilities possible In addition to these the low pass filters and the band pass filters are selected by an electric signal from the CPU and it makes a no tune up system DUAL VFO Dual VFO s controlled by a large tuning knob provide easy access to split frequencies used in DX operation Normal tuning rate is in 10Hz increments and increasing the speed of rotation of the main tuning knob shifts the tuning to 100Hz incre ments automatically Pushing the tuning speed button gives 1 KHz tuning Digital outputs are available for computer control of the transceiver frequency and functions and for a synthesized voice frequency readout 32 MEMORIES Thirty two tunable memories are provided to store mode HAM GENERAL COVERAGE mode and frequency and the RAM is backed up by an internal lithium memory backup battery to maintain the memories for up to seven years Scanning of frequencies memories and bands are possible from the unit or from the IC HM12 scanning microphone In the Mode S mode only those memories with a particular mode are scanned others are bypassed Data may be transferred between VFO s from VFO to memories or from memories to VFO OUTSTANDING RECEIVER PERFORMANCE Utilizing an ICOM developed J FET DBM the IC 751 has a 105dB dynamic range The 70 4515MHz first IF virtually eliminates spurious responses and a high gain 9 0115MHz second IF with ICOM s PBT selectivity A deep IF notch filter adjustable AGC and noise blanker can be adjusted to eliminate the woodpecker audio tone control plus RIT with separate readout provides easy to adjust clear reception even in the presence of strong QRM or high noise levels A low noise receiver preamp provides exceptional reception sensitivity as required TRANSMITTER The transmitter features high reliability transistors in a low IMD 32dB 100W full 100 duty cycle internal cooling fan standard 12 volt DC design Quiet relay selection of transmitter LPF s transmit addio tone control monitor circuit to monitor your own CW or SSB signal XIT and a high performance speech processor enhance the IC 751 transmitter s opera tion For the CW operator semi break in or full QSK is provided for smooth fast break in keying OTHER FEATURES All of the above features plus full function metering SSB and FM squelch convenient large controls a large selection of plug in filters and a new high visibility multi color flourescent display that shows frequency in white and other functions in white or red make the IC 751 your best choice for a superior grade HF base transceiver 2
