SECTION 6 OPTION INSTALLATION The following tools are needed for the installation of the options Phillips Screwdriver Screwdriver Solder De soldering braid Diagonal cutters Soldering Iron 40W Soldering tool Before performing any work on the set make sure that the power cord is detached from the transceiver After optional filters are installed and PBT control function as follows Remove the top and bottom covers by unscrewing the six screws each on the top and bottom and the three screws on each side while taking care not to damage the internal speaker and unplug its connector 1 When the FL 70 SSB wide filter is installed FILTER SWITCH OFF ON BANDWIDTH NARROW WIDE the FILTER switch PBTCONTROL EFFECTIVE NO WORK 2 When CW narrow filter is installed FILTER SWITCH OFF ON 6 1 INSTALLATION OF OPTIONAL FILTER 6 1 1 OPTIONAL FILTERS PREPARED We have prepared various optional filters as follows FL 32 FL 63 FL 33 FL 70 F L 52A FL 53 A CENTER FREQUENCY 9 0106MHz 9 0106MHz 9 0100MHz 9 0115MHz 455 0KHz 455 0KHz CHARACTERISTICS 250Hz 6dB 800Hz 60dB 125Hz 6dB 550Hz 60dB 3 0KHz 6dB 10KHz 60dB 1 4KHz 6dB 2 5KHz 60dB 250Hz 6dB 500Hz 60dB 125Hz 6dB 240Hz 60dB BANDWIDTH WIDE NARROW PBT CONTROL EFFECTIVE EFFECTIVE The control works as IF SHIFT function and tone pitch can be adjusted USABLE MODE CW R TTY CW R TTY AM SSB Wide CW R TTY CW R TTY 3 When FL 33 AM filter is installed When installing FL 33 cut the lead of W116 on the MAIN unit board Refer the photo The IC 751 has two positions for installing optional filters The B position is for a 9MHz filter one of the FL 32 FL33 FL 63 and FL 70 and the D position is for a 455KHz filter one of the FL 52A and FL 53A FILTER SWITCH OFF ON BANDWIDTH NARROW WIDE PBTCONTROL NO WORK NO WORK Please choose an optional filter which is suitable to your needs 6 1 2 ASSEMBLY PROCEDURE When installing FL 52A or FL 53A simply plug it into the specified position When installing a 9MHz filter 1 Remove nine screws at each edge and the center of the MAIN unit board and four screws at each corner of the FM unit board 28
