4 2 TOP COVER PREAMP ATT SWITCH ANTI VOX CONTROL MARKER SWITCH MONITOR LEVEL CONTROL MARKER CALIBRATOR 51 MARKER SWITCH Turns the marker circuit ON or OFF The marker fre quency is available on every 10KHz 50 PREAMP ATT Attenuator SWITCH Switches RF preamplifier and attenuator in the RF circuit When the switch is in the OFF position both preamplifier and attenuator are removed from the circuit and incoming signals will be fed to the receiver directly When using a small antenna or receiving a weak signal set the switch in the PRE position and the preamplifier is put in the RF circuit and provides higher sensitivity When nearby signals interfere with reception or receiving a very strong signal set this switch in the ATT position This removes the preamplifier from the circuit and inserts the attenuator into the circuit This gives about 20dB attenuation 52 ANTI VOX CONTROL In VOX operation the VOX circuit may be operated by sound from the speaker causing a switch to transmit This trouble can be prevented by adjusting the input level of the ANTI VOX circuit with this control along with the VOX gain control so that the VOX circuit only operates by the operator s voice not by sound from the speaker 53 MONITOR LEVEL CONTROL Controls the audio level of the monitoring SSB or CW side tone when the MONITOR switch on the front panel is turned ON Adjust the control for comfortable monitoring 54 MARKER CALIBRATOR Calibrates the marker frequency with a standard frequency such as the WWV For normal operation leave this switch in the OFF position 4 3 REAR PANEL CONNECTIONS RECEIVER ANTENNA OUTPUT TERMINAL KEY JACK T R CONTROL TERMINAL ANTENNA CONNECTOR EXTERNAL SPEAKER JACK DC POWER SOCKET EXTERNAL ALC TERMINAL ACCESSORY SOCKET RECEIVER INPUT TERMINAL SPARE TERMINAL OPTIONAL INTERFACE UNIT CONNECTOR POSITION GROUND TERMINAL OPTIONAL BUILT IN AC POWER SUPPLY CONNECTOR POSITION PLATE A TRANSVERTER TERMINAL 10
