on the frequency display In addition the letters MEMO are also displayed above the memory channel number to indicate the set is in the MEMORY CHANNEL MODE Turning the TUNING CONTROL clockwise FOR EXAMPLE When 14 271 MHz and USB are memorized in VFO A and 29 625MHz and FM are in MEMORY CHANNEL 1 by pushing the power switch ON the frequency display shows 14 271 0 USB VFO A and memory channel number 01 By pushing the VFO MEMORY switch the display will show 29 625 0 and FM memory channel number 01 and the letters MEMO above the channel number IN MEMORY CHANNEL MODE In the MEMORY CHANNEL MODE by pushing the DFS DIAL FUNCTION SELECT switch in the operating memory channel is locked on the displayed one and by turning the TUNING CONTROL the OPERATING FRE QUENCY displayed on the frequency display can be changed This is very convenient for tuning a slightly off frequency or to change the operating frequency or to rewrite the memorized frequency in the selected memory channel By turning the TUNING CONTROL memory channels can be selected Turning clockwise increases the channel number and counterclockwise decreases the number and the respective frequency mode and HAM GENE mode are displayed on the display When you select a memory channel that has never been stored any frequency the frequency display does not show any frequency but MHz and KHz decimals However the set works with the frequency and mode of the memory channel or VFO which was previously displayed FOR EXAMPLE Now you are operating on 14 271 MHz and USB with memory channel 7 If you want to change this frequency push the DFS switch in now you can change the displayed frequency By turning the TUNING CONTROL clockwise increases the frequency and counterclockwise decreases one the same as a VFO To tune to 14 295MHz turn the TUNING CONTROL clockwise to obtain the desired frequency 14 295 0 on the display FOR EXAMPLE When 7 012MHz and CW are memorized in memory channel 2 and no frequency is in channel 3 by turning the TUNING CONTROL clockwise the frequency display will show 7 012 0 CW MEMO and memory channel number 02 Bu turning the TUNING CONTROL clockwise furthermore the memory channel number will change to 03 but the channel has never memorized any frequency thus the display shows CW and only the MHz and KHz decimals However the set works with the frequency and mode of channel 2 i e 7 012MHz and CW Pushing the DFS switch in and turning the TUNING CONTROL When memory channel limits are reached i e 01 or 32 the next memory channel entered will be the opposite limit i e 32 or 01 USB U3DLn 1 1 L J J LI 18 MEMO LI
