In the HAM BAND mode DOWN 7 050 0 UP 7 050 0 3 550 0 10 050 0 1 900 0 4 28 050 0 24 550 0 The differences of the frequency of the various modes 14 050 0 18 050 0 0 6KHz ____________ 3KHz 21 050 0 24 550 0 4 28 050 0 1 900 0 3 550 0 21 050 0 18 050 0 4 14 050 0 10 050 0 In the HAM BAND SSB mode the sideband will be auto matically selected to the one usually used on the band i e upper sideband USB for the 10MHz band and above and lower sideband LSB for the 7MHz band and below If reverse sideband is desired push the FUNCTION key first then push the SSB switch 5 1 3 TUNING CONTROL Rotating the TUNING CONTROL clockwise increases the frequency while turning counterclockwise decreases the frequency in 10Hz steps By turning the tuning control faster the 100Hz steps tuning rate is automatically selected However in the GENERAL COVERAGE mode when the operating frequency reaches the highest or lowest edge of that MHz range by turning the TUNING CONTROL con tinuously at this time the BAND SELECT FUNCTION switch is not pushed in the operating frequency will go to the next MHz range When the TUNING RATE switch is pushed in the 1KHz steps tuning rate is selected in any mode At this time the 100Hz digit of the frequency display is cleared to 0 5 1 4 FREQUENCY DISPLAY ON EACH MODE When the 7MHz band and LSB are selected the display will be as follow The frequency range of each band in the HAM band mode is shown in the following chart LSB H L H H n 1 U J U U LI VFO A When changing to other modes the display will be as follows USB USB Tnu1n U1 n 1 u i u Band Frequency Range 1 8 1 800 0 1 999 9 3 5 3 440 0 4 099 9 7 0 6 950 0 7 499 9 10 0 9 950 0 10 499 9 14 0 13 950 0 14 499 9 VFO A CW 1 0 3 3 3 CW ri 1 U1 VFO A RTTY RTTY 1 0 3 3 3 n1 18 0 17 950 0 18 499 9 21 0 20 950 0 21 499 9 24 0 24 450 0 25 099 9 28 0 27 950 0 29 999 9 LI 1 VFO A In the HAM BAND mode by turning the TUNING CONT ROL clockwise the operating frequency reaches to the high edge of the band for example 14 499 9MHz and further turning of the control brings the frequency to the low edge of the band 13 950 0MHz then continues up the fre quency from there Likewise by continuing to turn the TUNING CONTROL counterclockwise beyond the low edge of the band the frequency jumps up to the high edge and goes down from that frequency FM Tncin FM n LI 1 i U 3 i u VFO A AM AM 1 n LH J U n LI n1 LI 1 VFO A The displayed frequency shows the carrier frequency To avoid the trouble of recalibrating the dial when you change the operating mode the displayed frequency is set to shift to the carrier frequency of each mode automatically For the differences of frequency shifts of the various modes refer to the following figure In the GENERAL COVERAGE mode by turning the TUN ING CONTROL clockwise the operating frequency reaches the highest one of that MHz range for example 14 999 9 13
