FOR EXAMPLE When VFO A is 14 271MHz and USB and VFO B is 29 670MHz and FM pushing the VFO switch to select VFO A then the VFO EQUALIZING switch VFO B s frequency and operating mode become the same as VFO A s 14 271MHz and USB Now the VFO A s frequency is memorized in the VFO B and you can operate anywhere with VFO A or B When you want to return to the pre vious frequency 14 271 MHz switch back to the other VFO To reverse this A the same as B select VFO B first then the VFO EQUALIZING switch It also allows you to search for a clear frequency with one VFO while keeping your operating frequency on the other VFO When you have found a clear frequency switch back to your operating frequency inform the station you are in contact with of the new frequency and switch back It s that simple 5 1 8 DUPLEX SPLIT SWITCH The DUPLEX SPLIT switch changes the relationship of the two VFO s Each push turns the function ON and OFF alternately When the function is OFF one VFO is for both receive and transmit When the function is ON the letters DUP are displayed on the frequency display and one VFO is for receive and the other VFO is for transmit So that this will allow you to operate on split receive transmit frequencies VFO A displayed USB IUJT II L I n I LI VFO A VFO B hidden FOR EXAMPLE Set VFO A to 7 057MHz and VFO B to 7 255MHz Push the VFO switch to return VFO A then the DUPLEX SPLIT switch to ON 7 057MHz will be shown on the display during receive VFO A and 7 255MHz during transmit VFO B You are now receiving on 7 057MHz and transmitting on 7 255MHz Pushing the VFO switch to reverse the above Pushing the VFO EQUALIZING switch VFO A displayed LSB Receiving VFO A T n c I n I LI J I LI VFO B hidden n LI VFO A 5 1 10 RIT RECEIVE INCREMENTAL TUNING By using the RIT circuit you can shift the receive fre quency 9 9KHz maximum either side of the transmit frequency without moving the transmit frequency itself Therefore when you get a call slightly off frequency or when the other station s frequency has been drifted you can tune in the frequency without disturbing the transmitt ing frequency Transmitting VFO B Each VFO stores operating mode too If different mode is stored in each VFO a crossmode OSO can be possible as well By pushing the RIT switch the RIT circuit is turned ON and the letters RIT and shifted frequency are displayed on the frequency display The receive frequency can be shifted 10Hz steps by turning the INCREMENTAL TUNING CONTROL First pushing the RIT switch to turn ON the RIT RIT USB uJ 1 1 L 6 TO L LI n LI n LI Fl 1 LI 1 VFO A Receiving and transmitting on 14 267 8MHz Turning the RIT control counter clockwise 5 1 9 TRANSFERRING VFO FREQUENCY The VFO EQUALIZING switch allows either VFO s to be brought to the exact frequency of the other VFO without turning the tuning control and the operating mode RIT USB 11 _ 6 TO L LI 3 3 n1 LI 1 VFO A Receiving on 14 263 9MHz and transmitting on 14 267 8MHz 15
