Connect the internal speaker connector and replace the bottom and top covers of the set Plug P1 of the power supply unit to the DC Power Socket of the set 6 2 4 OPERATION 1 Connect the DC output plug P1 of this unit into the transceiver DC power Socket securely At this time make sure that A The power switch on the transceiver is OFF B The T R switch is in the RECEIVE position C The PTT switch on the microphone is not depressed D The VOX switch is in the OFF position 2 Connect the supplied AC power cord into the AC power socket newly installed on the rear panel of the tran sceiver Then connect the AC power plug into an AC power outlet 3 By turning the transceiver power switch ON this unit will be turned ON and supply a DC 13 8V to the tran sceiver 6 2 5 CAUTION 1 Ground the GROUND TERMINAL of the set with as short a wire as possible to prevent electrical shock TV I BCI and other problems 2 This unit stops the output voltage with a protection circuit when output voltage is shorted or consumed load current exceeds 25A When the output voltage is stopped turn the power switch of the transceiver OFF and remove the cause of the problem 3 If the fuse blows replace it with a 10A at 117V or 5A at 240V fuse after checking the cause of the problem Use a Philips screwdriver to open the holder The outside ring of the holder cannot be rotated 30
