Chapter 1: Product Introduction
1-4
1.3 Systemspecications
The ASUS RS720-E9-RS8/RS8-G features the ASUS Z11PP-D24 server board. The server
supports Intel
®
Xeon
®
Scalable Processors Family Series plus other latest technologies
through the chipsets onboard.
Model Name RS720-E9-RS8 RS720-E9-RS8-G
Motherboard
Z11PP-D24
Processor Support
2 x Socket P0 (LGA 3647)
1st Gen Intel
®
Xeon
®
Processor Scalable Family
2nd Gen Intel
®
Xeon
®
Processor Scalable Family
UPI 10.4 GT/s
Core Logic
Intel
®
PCH C621
Memory
Total Slots
24 (6-channel per CPU, 12 DIMM per CPU)
Capacity
Maximum up to 9216GB
Memory Type
DDR4 2933* (1 DIMM per Channel)
DDR4 2666/2400/2133 RDIMM/LRDIMM/LRDIMM 3DS
(2 DIMM per Channel)
Intel
®
Optane™ DC persistent memory (DCPMM)
* 2933MHzwilldropto2666MHzwhenusing2DPCcongurations
** Refer to ASUS server AVL for the latest update
Memory Size
4GB, 8GB, 12GB, 32GB, 64GB (RDIMM)
64GB, 128GB, 256GB (RDIMM 3DS)
32GB, 64GB, 128GB (LRDIMM)
64GB, 128GB ,256GB (LRDIMM 3DS)
128GB, 256GB, 512GB (DCPMM)
* Refer to ASUS server AVL for the latest update
Expansion
Slots
Total PCI/PCI-X/
PCI-E/PIKE Slots
8+1 6+1
Slot Type
6 x PCI-E x16 (Gen3 x8 link) or
3 x PCI-E x16 (Gen3 x16 link),
FH, HL
1 x PCI-E x16 (Gen3 x16 link),
LP, HL
1 x PCI-E x16 (Gen3 x8 link),
FH, HL
1 x OCP Mezzanine 2.0 (Gen3
x16 link)
2 x PCI-E x16 (Gen3 x16 link),
FH, FL (for GPU*2)
2 x PCI-E x16 (Gen3 x8 link) or
1 x PCI-E x16 (Gen3 x16
link), FH, HL
1 x PCI-E x16 (Gen3 x16 link),
LP, HL
1 x PCI-E x16 (Gen3 x8 link),
FH, HL
1 x OCP Mezzanine 2.0 (Gen3
x16 link)
(continued on the next page)
