Chapter 1: Product Introduction
1-6
Model Name RS720-E9-RS8 RS720-E9-RS8-G
Disk
Controller
SATA
Controller
Intel
®
PCH C621
10 x SATA 6Gb/s ports + 1 x M.2 connector (SATA 6Gb/s & PCI-E
Gen3 x4 link) or 9 x SATA 6Gb/s ports + 2 x M.2 connector
(SATA 6Gb/s & PCI-E Gen3 x4 link)
Intel
®
RSTe
(for Windows and Linux; Support software RAID 0, 1, 10 & 5)
Intel
®
VROC
(for Windows and Linux; Support software RAID 0, 1, 10 & 5)
SAS
Controller
Optional:
ASUS PIKE II 3008 8-port SAS HBA card
ASUS PIKE II 3108 8-port SAS HW RAID card
12G SAS Support
Management
Solution
Out of Band
Remote
Hardware
On-Board ASMB9-iKVM for KVM-over-IP
Software
ASUS Control Center (Classic)
OS Support
Please nd the latest OS support from http://www.asus.com/
Dimension (Depth x Width x
Height)
750 mm x 444 mm x 88 mm (2U)
29.52” x 17.48” x 3.46”
Power Supply
(differentconguration
by region)
1+1 Redundant
800W 80 PLUS
Platinum Power Supply
850W 80 PLUS
Titanium Power Supply
Rating: 100-127Vac/
200-240Vac, 10A/5A, 50/60Hz,
Class I (240Vdc only for China)
1+1 Redundant
1200W 80 PLUS
Platinum Power Supply
(for 165W CPU and below)
* When input voltage is 110V,
power supply redundancy will
be lost.
1300W 80 PLUS
Platinum Power Supply
(for 205W CPU)
Rating: 100-127Vac/
200-240Vac, 10A/5A, 50/60Hz,
Class I (240Vdc only for China)
Environment
Operating temperature: 10°C ~ 35°C
Non operating temperature: -40°C ~ 60°C
Non operating humidity: 20% ~ 90% (Non condensing)
*Specicationsaresubjecttochangewithoutnotice.
