Asus RS720-E9-RS8-G [83/206] Cable connections
![Asus RS720-E9-RS8-G [83/206] Cable connections](/views2/1771511/page83/bg53.png)
2-55
ASUS RS720-E9-RS8/RS8-G
2.6 Cable connections
• Thebundledsystemcablesarepre-connectedbeforeshipment.Youdonotneedto
disconnect these cables unless you are going to remove pre-installed components to
install additional devices.
• RefertoChapter4fordetailedinformationontheconnectors.
Pre-connected system cables
1. 8-pin BPPWR1 power connector (from power supply to backplane)
2. Auxiliarypanel1connector(frommotherboardtofrontI/Oboard)
3. Auxiliarypanel2connector(frommotherboardtofrontI/Oboard)
4. Systemfanconnectors(frommotherboardFAN1-8tosystemfans)
5. Panelconnector(frommotherboardtofrontI/Oboard)
6. OCU-USBtoUSBconnector(frommotherboardtofrontI/Oboard)
7. SATA connectors (from motherboard to SATA/SAS backplane board)
8. ISATA connectors (from motherboard to SATA/SAS backplane board)
