2-45

ASUS RS720-E9-RS8/RS8-G

3. Place the riser card bracket 1 on

aatandstablesurfaceinthe

orientation as shown.

4. Prepare the ASUS PCIE-

NVME4-OCuLinkcard.

5. ConnecttheOCuLinkcablesto

the corresponding slots.

6. InstalltheASUSPCIE-NVME4-

OCuLinkcardintothePCIEslot.

7. Installtherisercardbracket1andtheASUSPCIE-NVME4-OCuLinkcardassembly

into the PCIE1 slot on the motherboard. Ensure that the golden connectors of the riser

cardbracket1isrmlyseatedinplace.

8. Secure the riser card bracket 1 to the chassis with the screw removed in step 1.
