ASUS RS540-E8-RS36-ECP
1-5
*Specifications are subject to change without notice.
Model Name
RS540-E8-RS36-ECP
Networking
LAN
2 x Intel I210AT
1 x Management Port
Graphic
VGA
Aspeed AST2400 32MB
Front I/O Ports
2 x USB 2.0 ports
I/O Connector and Switch/LED
Rear I/O Connector and Switch/LED:
1 x External Serial Port (COM Port)
2 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port
1 x Q-Code/Port 80 LED
2 x USB 3.0 ports
1 x VGA port
1 x PS/2 KB/Mouse port
OS Support
Windows
®
Server 2012 R2
Windows
®
Server 2012
Windows
®
Server 2008 R2
RedHat
®
Enterprise Linux
SuSE
®
Linux Enterprise Server
CentOS
Ubuntu
VMware
Citrix XenServer
Please find the latest OS support from http://www.asus.com/
Management
Solution
Software
ASWM Enterprise
Out of Band
Remote
Management
On-Board ASMB8-iKVM for KVM-over-IP
Dimension (HH x WW x DD)
615mm x 444mm x 176mm (4U)
Net Weight Kg
(CPU, DRAM & HDD not
included)
23 Kg
Power Supply
1+1 Redundant 800W 80 PLUS Platinum Power Supply
Power Rating
100-127/200-240Vac, 10A/5A, 50/60Hz, Class I
Environment
Operating temperature: 10
°
C – 35
°
C
Non operation temperature: -40
°
C – 70
°
C
Non operation humidity: 20% – 90% (Non condensing)
