vii
Contents
Chapter 7: Driver Installation
7.1 RAID driver installation .............................................................................7-2
7.1.1 Creating a RAID driver disk......................................................... 7-2
7.1.2 Installing the RAID controller driver............................................. 7-4
7.2 Management applications and utilities installation ..............................7-14
7.3 Running the Support DVD ......................................................................7-14
7.4 Intel
®
chipset device software installation ............................................7-18
7.5 Installing the Intel
®
I350-AM1/I350-AM2/I210 X540-BT2
Gigabit Adapters driver ...........................................................................7-20
7.6 VGA driver installation ............................................................................7-23
7.7 Intel
®
Rapid Storage Technology enterprise 4.0 installation ............... 7-25
Appendix
ASUS contact information ...................................................................................... A-2
