7
Accessories
7-2
Optional accessories
Name of option Remark:
FHY-GZ
35 45
Drain pump kit KDUJ5F50
Replacement long-life filter Resin net KAFJ501F56
L-type piping kit (for upward direction) for FHY KHFJ5F50
Remote control (wired type) for FHY BRC1B517
Central remote control DCS302B51
unified ON/OFF control DCS301B51
Schedule timer DST301B51
Adaptor for wiring KRP1B54
Group control adaptor PCB (*1) KRP4A52
Interface adaptor for Sky Air series DTA102A52
Installation box for adaptor PCB KRP1B93
Note *1: Installation box for adaptor PCB (KRP1B93) is necessary
Name of option Remark FHYP-BV1, FH-BZV1
35 45 60 71 100 125
Replacement long-life filter
KAFJ501D56 KAFJ501D80 KAFJ501D112 KAFJ501D160
Drain up kit
KDU50B50VE KDU50B71VE KDU50B125VE
L-type piping kit (for upward direction) For FHY
KHFJ5F50 KHFJ5F80 KHFJ5F160
For FH
KHFJ5F50 KHFJ5F60
Remote controller Wired type
BRC1C517
Infrared type For FHY
BRC7E63W
For FH
BRC7E66
Central remote control
DCS302B61
Unified ON/OFF control
DCS301B61
Schedule timer
DST301B61
Adaptor for wiring
KRP1B54
Wiring adapter for electrical appendices z1
KRP4A52
Interface adaptor for Sky Air series
DTA102A52
Installation box for adaptor PCB
KRP1C93
3D028285
Note *1: Installation box for adapter PCB (KRP1C93) is necessary.
